Mahindra XEV 9S Specifications, Performance & Features.

Specifications & Features.

Key Specifications

Fuel TypeElectric

Engine-

TransmissionAutomatic

Power228 bhp

Battery Charging & Range

AC Fast Charging0 - 100 % : 6 hrs

Officially Certified Range (km)521 km MIDC Certified Range

Charger Connection TypeCCS2

Portable EV Charging CableYes

Regenerative Braking5 Level Regenerative Braking Configurable with Paddle Shifters

Charging Indicator On Light BarYes

Transmission & Drivetrain

TransmissionAutomatic

DrivetrainRWD

Four-Wheel-DriveNo

Differential LockNo

Drive Modes5 - Default, Range, Everyday, Race, Snow

Terrain ModesNo

Chassis TypeUnibody/Monocoque Frame

Suspension

Front SuspensionMcPherson Strut i-link Independent Suspension & Stabilizer bar

Rear SuspensionMulti-link (5-link) Independent Suspension & Stabilizer bar

Advanced Suspension Features No

Capacity & Dimensions

Length *Width *Height4737 mm * 1900 mm * 1747 mm

Wheelbase2762 mm

Seating Capacity7 Seats and 3 Rows

Doors5 Doors

Minimum Turning Radius5 metres

Frequency Selective Damping (FSD)Yes

Ground Clearance201 mm (unladen)

Tyre & Wheels

WheelsSteel Rims

Front Tyres235 / 60 R18

Rear Tyres235 / 60 R18

Spare Wheel & TyreSteel (135/80R18), Located in Boot

TyresRoad Radial - Tubeless Tyres

Warranty

Battery WarrantyLifetime warranty (For First Registered Owner. Applicable for Private Registration only. In case of ownership change, warranty on the HV battery shall be 10 years from date of first registration or 2,00,000 kms- whichever is earlier.)

Battery Performance

Fuel TypeElectric

BatteryLithium Iron Phosphate, 59 kWh, Placed Under Floor Pan

Max Power (bhp@rpm)228 bhp

Max Torque (Nm@rpm)380 Nm

Idle Start/StopNo

Electric MotorSingle Permanent Magnet Synchronous Motor (Mounted at Rear Axle)

Top Speed200 kmph

ADAS & Active Safety

Tyre Pressure Monitoring SystemYes

ADASNo

Forward Collision WarningNo

Lane FunctionsNo

Rear Collision AssistNo

High-beam AssistNo

Emergency Brake Light Flashing No

Anti Theft AlarmYes

Passive Safety (Airbags, NCAP Ratings, etc.)

Airbags6 Airbags (Driver, Front Passenger, 2 Curtain, Driver Side, Front Passenger Side)

NCAP RatingNot Tested

SeatbeltsYes

Child Seat Anchor PointsYes

Engine ImmobiliserYes

Puncture Repair KitNo

Second Row Middle Seat SafetyRear Middle Three Point Seatbelt

Child Safety LockYes

Brakes

BrakesDisc (Front & Rear)

Anti-Lock Braking System (ABS)Yes

Electronic Stability Program (ESP)Yes

Brake Assist (BA)Yes

Electronic Brake-force Distribution (EBD)Yes

Traction Control System (TC/TCS)Yes

AC & Climate Control

Air ConditionerAutomatic Climate Control (Front AC: Single Zone with Fan speed control, Second row AC: Blower with Vents Behind Front Armrest, Third row AC: Blower with Fan speed control with Vents on Side Panels)

HeaterYes

Air PurifierNo

Doors, Mirrors & Wipers

Central LockingKeyless

Interior Door Handles FinishSilver

Adjustable ORVMsElectrically Adjustable

Inside Rear View Mirror (iRVM)Manual Dimming

Rear DefoggerYes

ORVMs Tilt on ReverseNo

Rear WiperYes

Exterior Door Body Coloured Door Handles, Pull Handles Type

Sunroof & Windows

SunroofPanoramic Sunroof, Voice Controlled

Power WindowsFront & Rear Power Windows, Driver One-touch up/down

Window SunshadeNo

Driver Assistance (Park Assist, Cruise Control, etc.)

Keyless Start/ Button StartYes

Parking AssistReverse Camera with Guidance

Parking SensorsRear

Cruise ControlYes

Storage

Bottle Holder in DoorsAll Doors

Door PocketsFront & Rear

Front Seatback PocketsYes

Sunglass HolderYes

Cabin Boot AccessYes

Third Row Cup HoldersYes

Umbrella Storage in DoorNo

Cup Holders6 Cupholders in Front, Second & Third Row

Seating & Ergonomics

Driver Seat Adjustment8 way manually adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down, seat height: up / down)

Front Passenger Seat Adjustment6 way manually adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down)

Second Row Seat Adjustment6 way manually adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down)

Seat UpholsteryFabric

HeadrestsFront, Second & Third

Split Rear Seat60:40

Rear Passenger Seat TypeBench

Rear ArmrestCup Holder

Infotainment & Entertainment

Infotainment Screen12.3" HD Triple-screen Display

Audio System6 Speakers

AM/FM RadioYes

Bluetooth CompatibilityPhone Calls & Audio Streaming

Smart ConnectivityAndroid Auto (Wireless) & Apple CarPlay (Wireless)

Input Methods Bluetooth Compatibility (Phone Calls & Audio Streaming), Smart Watch Connectivity

AntennaShark Fin Antenna

Gesture ControlNo

Instrument Cluster

Instrument Cluster ScreenDigital Instrument Cluster

SpeedometerDigital

ClockDigital

Gear IndicatorNo

Fuel ConsumptionDistance to Empty

Heads Up Display (HUD)No

Trip Meter2 Trips Electronic

Average SpeedYes

Steering

Steering AdjustmentTilt & Telescopic

Steering-Mounted ControlsYes

SteeringPower-assisted (Electric) steering with 2 spokes

Lighting & Visibilty

HeadlightsBi-LED Projector

Daytime Running Lights (DRL)LED

Fog LightsNo

Ambient Interior LightingNo

Interior LampsSwitch Controlled Front and Rear LED Cabin lamps, Boot Lamp

Automatic HeadlampsYes

Cornering HeadlightsNo

Headlight Height AdjusterYes

Mobile App & Remote Controls

Over The Air (OTA) UpdatesYes

Emergency Call ButtonYes

Find My CarYes

Geo-fenceYes

Check Vehicle Status via AppYes

Remote AC: On / Off via AppYes

Remote Car Lock/Unlock via AppYes

Remote Engine Start/StopYes

Design & Styling

InteriorDual Tone

Roof RailsYes

SpoilerYes

WrappingsLeatherette Wrapped Steering Wheel

Body-coloured BumpersYes

Rub-stripsNo

Body KitCladding - Body Coloured

Skid PlateFront & Rear

Warning & Alerts

Overspeed Warning1 beep over 80kmph, Continuous beeps over 120kmph

Door Ajar WarningNo

Seat Belt WarningYes

Headlight and Ignition on ReminderYes

Boot Open WarningYes

Colors

Everest White

*Prices are ex-showroom in New Delhi. Specifications may vary for different variants.
