Mercedes-Benz V-Class Specifications & Features

Mercedes-Benz V-Class Specifications

• Engine & Transmission

  Engine	1951 cc, 4 Cylinders Inline, 4 Valves/Cylinder, DOHC
  Engine Type	M254
  Fuel Type	Diesel
  Max Power (bhp@rpm)	233 bhp
  Max Torque (Nm@rpm)	500 Nm
  Drivetrain	RWD
  Transmission	Automatic (TC) - 9 Gears
  Emission Standard	BS6 Phase 2

• Dimensions & Weight

  Length *Width *Height	5370 mm * 1928 mm * 1880 mm
  Wheelbase	3430
  Kerb Weight	2486

• Capacity

  Doors	5
  Seating Capacity	6 Seats and 3 Rows
  Bootspace	5010 L (measured up to the roof) – 5010 L (rear seats folded)
  Fuel Tank Capacity	70

• Suspensions, Brakes, Steering & Tyres

  Front Suspension	Air Suspension
  Steering	Power-assisted (Electric) steering with 3 spokes
  Rear Suspension	Air Suspension
  Minimum Turning Radius	5.6
  Tyres	Radial - Tubeless Tyres
  Wheels	Alloy Wheels
  Front Tyres	18
  Rear Tyres	18

• Engine Performance

  Fuel Type	Diesel
  Engine Type	M254
  Engine	1951 cc, 4 Cylinders Inline, 4 Valves/Cylinder, DOHC
  Max Power (bhp@rpm)	233 bhp
  Max Torque (Nm@rpm)	500 Nm
  Emission Standard	BS6 Phase 2

• Transmission & Drivetrain

  Transmission	Automatic (TC) - 9 Gears
  Drivetrain	RWD

• Suspension

  Front Suspension	Air Suspension
  Rear Suspension	Air Suspension

• Capacity & Dimensions

  Length *Width *Height	5370 mm * 1928 mm * 1880 mm
  Wheelbase	3430
  Seating Capacity	6 Seats and 3 Rows
  Fuel Tank Capacity	70
  Doors	5
  Minimum Turning Radius	5.6
  Kerb Weight	2486

• Tyre & Wheels

  Wheels	Alloy Wheels
  Front Tyres	18
  Rear Tyres	18
  Tyres	Radial - Tubeless Tyres

Mercedes-Benz V-Class Features

• Mobile App Features

  Find My Car	Yes
  Emergency Call Button	Yes
  Geo-fence	Yes
  Check Vehicle Status via App	Yes

• Safety

  NCAP Rating	Not Tested
  Blind Spot Detection	Yes
  Overspeed Warning	1 beep over 80kmph, Continuous beeps over 120kmph
  Emergency Brake Light Flashing	Yes
  High-beam Assist	Yes
  Lane Departure Warning	Yes
  ADAS	Level 2
  Airbags	7 Airbags (Driver, Front Passenger, 2 Curtain, Driver Side, Front Passenger Side, Front Centre)
  Automatic Emergency Braking	Yes
  Boot Open Warning	Yes
  Seatbelts	Yes
  Child Seat Anchor Points	Yes
  Seat Belt Warning	1
  Driver Drowsiness Detection	Yes
  Lane Functions	Lane Departure Prevention, Lane Keep Assist
  Rear Collision Assist	Blind Spot Monitor, Lane Change Assist and Rear Cross-traffic Assist
  Reflectors	Rear Bumper
  Tyre Pressure Monitoring System	Yes
  Automatic Park Lock	Yes
  Height Adjustable Seat Belt	Yes

• Braking & Traction

  Anti-Lock Braking System (ABS)	Yes
  Brakes	Disc (Front & Rear)
  Electronic Brake-force Distribution (EBD)	Yes
  Brake Assist (BA)	Yes
  Electronic Stability Program (ESP)	Yes
  Hill Hold Control	Yes
  Traction Control System (TC/TCS)	Yes

• Locks & Security

  Engine Immobiliser	Yes
  Central Locking	Yes
  Speed Sensing Door Lock	Yes
  Child Safety Lock	Yes

• Comfort & Convenience

  Heater	Yes
  Cabin Boot Access	Yes
  Charging Ports	12V Power Outlet
  Parking Assist	360 Degree Camera
  Parking Sensors	Front & Rear
  Headlight and Ignition On Reminder	Yes
  Steering Adjustment	Electric Tilt & Telescopic
  Fuel Fillers Lid	Yes

• Seats & Upholstery

  Massage Seats	Yes
  Driver Seat Adjustment	14 way electrically adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down, seat height: up / down, lumbar: up / down, lumbar: forward / back, seat base angle: up / down) + 2 way manually adjustable (extended thigh support: f
  Front Passenger Seat Adjustment	14 way electrically adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down, seat height: up / down, lumbar: up / down, lumbar: forward / back, seat base angle: up / down) + 2 way manually adjustable (extended thigh support: f
  Second Row Seat Adjustment	4 way electrically adjustable (seat: forward / back, backrest tilt: forward / back) + 2 way manually adjustable (extended thigh support: forward / back)
  Wrappings	Leather Wrapped Gear Knob & Leather Wrapped Steering Wheel
  Seat Upholstery	Leather
  Driver Armrest	Yes
  Rear Passenger Seat Type	Captain Seats
  Ergo lever / Boss Mode	Yes
  Rear Armrest	Yes
  Folding Rear Seat	Flat
  Split Rear Seat	50:50
  Split Third Row Seat	50:50
  Front Seatback Pockets	Yes
  Headrests	Front, Second & Third
  Third Row Seat Type	Captain Seats

• Storage

  Cup Holders	6 Cupholders in Front, Second & Third Row
  Driver Armrest Storage	Yes
  Third Row Cup Holders	Yes
  Door Pockets	Front & Rear
  Bootspace	5010 L (measured up to the roof) – 5010 L (rear seats folded)
  Cabin Boot Access	Yes
  Boot Open Warning	Yes
  Front Seatback Pockets	Yes
  Boot Opener	Electric Opening and Closing

• Doors, Windows, Mirrors & Wipers

  Power Windows	Front & Rear Power Windows, All One-touch up/down
  Interior Door Handles Finish	Painted
  Adjustable ORVMs	Electrically Adjustable & Retractable
  Exterior Door	Sliding Doors, Body Coloured Door Handles, Pull Handles Type
  Rear Defogger	Yes
  Boot Opener	Electric Opening and Closing
  Rear Wiper	Yes
  Door Pockets	Front & Rear
  ORVM (Outside Rear View Mirrors)	Body-Coloured finish, Turn Indicators on ORVMs
  Inside Rear View Mirror (iRVM)	Auto-Dimming
  Window Sunshade	Rear Windows

• Exterior

  Body-coloured Bumpers	Yes
  Body Kit	Silver
  Roof Rails	Yes
  Exhaust	Yes
  Antenna	Yes

• Lighting

  Headlights	LED
  Daytime Running Lights (DRL)	LED
  Automatic Headlamps	Yes
  Follow Me Home Headlamps	Yes
  Taillights	LED
  Ambient Interior Lighting	Multi-colour (64)
  Stop Lamp	LED
  Interior Lamps	Front and Rear Reading Lamp,
  Headlight Height Adjuster	Yes

• Instrumentation

  Trip Meter	2 Trips Electronic
  Average Speed	Yes
  Speedometer	Digital
  Clock	Digital
  Door Ajar Warning	Yes
  Gear Indicator	Yes
  Fuel Consumption	Average Fuel Consumption & Distance to Empty
  Tachometer	Digital

• Entertainment, Information & Communication

  Infotainment Screen	12.3" Touch-screen Display
  Smart Connectivity	Android Auto
  Audio System	15 Burmester with Dolby Atmos Speakers
  Steering-mounted controls	Yes
  Voice Command	Yes
  GPS Navigation System	Yes
  AM/FM Radio	Yes
  Wireless Charger	Yes

• ADAS & Active Safety

  ADAS	Level 2
  Lane Functions	Lane Departure Prevention, Lane Keep Assist
  Rear Collision Assist	Blind Spot Monitor, Lane Change Assist and Rear Cross-traffic Assist
  Tyre Pressure Monitoring System	Yes
  High-beam Assist	Yes
  Emergency Brake Light Flashing	Yes
  Automatic Emergency Braking	Yes
  Driver Drowsiness Detection	Yes
  Blind Spot Detection	Yes
  Automatic Park Lock	Yes

• Passive Safety (Airbags, NCAP Ratings, etc.)

  Airbags	7 Airbags (Driver, Front Passenger, 2 Curtain, Driver Side, Front Passenger Side, Front Centre)
  NCAP Rating	Not Tested
  Seatbelts	Yes
  Child Seat Anchor Points	Yes
  Child Safety Lock	Yes
  Engine Immobiliser	Yes

• Brakes

  Brakes	Disc (Front & Rear)
  Anti-Lock Braking System (ABS)	Yes
  Electronic Brake-force Distribution (EBD)	Yes
  Electronic Stability Program (ESP)	Yes
  Traction Control System (TC/TCS)	Yes
  Hill Hold Control	Yes
  Brake Assist (BA)	Yes

• AC & Climate Control

  Heater

  Yes

• Doors, Mirrors & Wipers

  Central Locking	Yes
  Speed Sensing Door Lock	Yes
  Exterior Door	Sliding Doors, Body Coloured Door Handles, Pull Handles Type
  Fuel Fillers Lid	Yes
  ORVM (Outside Rear View Mirrors)	Body-Coloured finish, Turn Indicators on ORVMs
  Adjustable ORVMs	Electrically Adjustable & Retractable
  Inside Rear View Mirror (iRVM)	Auto-Dimming
  Rear Wiper	Yes
  Rear Defogger	Yes
  Interior Door Handles Finish	Painted
  Boot Opener	Electric Opening and Closing

• Sunroof & Windows

  Power Windows	Front & Rear Power Windows, All One-touch up/down
  Window Sunshade	Rear Windows

• Driver Assistance (Park Assist, Cruise Control, etc.)

  Parking Sensors	Front & Rear
  Parking Assist	360 Degree Camera

• Seating & Ergonomics

  Driver Seat Adjustment	14 way electrically adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down, seat height: up / down, lumbar: up / down, lumbar: forward / back, seat base angle: up / down) + 2 way manually adjustable (extended thigh support: f
  Front Passenger Seat Adjustment	14 way electrically adjustable (seat: forward / back, backrest tilt: forward / back, headrest: up / down, seat height: up / down, lumbar: up / down, lumbar: forward / back, seat base angle: up / down) + 2 way manually adjustable (extended thigh support: f
  Second Row Seat Adjustment	4 way electrically adjustable (seat: forward / back, backrest tilt: forward / back) + 2 way manually adjustable (extended thigh support: forward / back)
  Seat Upholstery	Leather
  Headrests	Front, Second & Third
  Folding Rear Seat	Flat
  Rear Passenger Seat Type	Captain Seats
  Driver Armrest	Yes
  Cabin Boot Access	Yes
  Massage Seats	Yes
  Ergo lever / Boss Mode	Yes
  Split Rear Seat	50:50
  Rear Armrest	Yes
  Height Adjustable Seat Belt	Yes
  Split Third Row Seat	50:50
  Third Row Seat Type	Captain Seats

• Infotainment & Entertainment

  Infotainment Screen	12.3" Touch-screen Display
  Audio System	15 Burmester with Dolby Atmos Speakers
  AM/FM Radio	Yes
  Smart Connectivity	Android Auto
  GPS Navigation System	Yes
  Charging Ports	12V Power Outlet
  Antenna	Yes
  Wireless Charger	Yes
  Voice Command	Yes

• Instrument Cluster

  Speedometer	Digital
  Tachometer	Digital
  Trip Meter	2 Trips Electronic
  Clock	Digital
  Gear Indicator	Yes
  Fuel Consumption	Average Fuel Consumption & Distance to Empty
  Average Speed	Yes

• Steering

  Steering	Power-assisted (Electric) steering with 3 spokes
  Steering Adjustment	Electric Tilt & Telescopic
  Steering-Mounted Controls	Yes

• Lighting & Visibilty

  Headlights	LED
  Daytime Running Lights (DRL)	LED
  Follow Me Home Headlamps	Yes
  Automatic Headlamps	Yes
  Headlight Height Adjuster	Yes
  Reflectors	Rear Bumper
  Taillights	LED
  Interior Lamps	Front and Rear Reading Lamp,
  Ambient Interior Lighting	Multi-colour (64)
  Stop Lamp	LED

• Mobile App & Remote Controls

  Emergency Call Button	Yes
  Find My Car	Yes
  Geo-fence	Yes
  Check Vehicle Status via App	Yes

• Design & Styling

  Wrappings	Leather Wrapped Gear Knob & Leather Wrapped Steering Wheel
  Body-coloured Bumpers	Yes
  Roof Rails	Yes
  Exhaust	Yes
  Body Kit	Silver

• Warning & Alerts

  Overspeed Warning	1 beep over 80kmph, Continuous beeps over 120kmph
  Door Ajar Warning	Yes
  Seat Belt Warning	1
  Boot Open Warning	Yes
  Headlight and Ignition on Reminder	Yes
